Visualization of sensor data integrated with a model. This sample also demonstrates a couple of extensions that can be activated from the command toolbar in the viewer: “Visual Report”, “Markup3D” and “Transform”.

If edit the material price in the database table, the price in the property window changes too. Properties pane has additional custom category “Database” (scroll to the bottom). Clicking on a material displays elements made from that materials. The materials list on the top right is from database. This sample connects a model with database. You can also select element type in a chart to highlight all elements of the given type in 2D and 3D view. Clicking on an element in 3D highlights the same element in the 2D view, and vice versa. Looks at the same model in different views. Try full screen, auto-rotate and explode mode, and see what happens. You can give it a try with your favorite model.įorge Viewer UI customization sample. Update : You can find more demos here: Viewerįree viewer site. Many of samples shown in the recordings in my previous post are available for you to try out yourself. Continuing with the previous post, when we talk about what Forge is and what you can do with it, the best way is to see demos.
